| Dia (D) | Flute Length (l) | Total Length (L) | Shank Dia (d) |
|---|---|---|---|
| R0.5 | 2 | 50 | 4 |
| R0.75 | 3 | 50 | 4 |
| R1 | 4 | 50 | 4 |
| R1.25 | 5 | 50 | 4 |
| R1.5 | 6 | 50 | 3 |
| R1.5 | 6 | 50 | 4 |
| R1.75 | 7 | 50 | 4 |
| R2 | 8 | 50 | 4 |
| R2.5 | 10 | 50 | 5 |
| R3 | 12 | 50 | 6 |
| R3.5 | 14 | 60 | 8 |
| R4 | 16 | 60 | 8 |
| R4.5 | 18 | 75 | 10 |
| R5 | 20 | 75 | 10 |
| R5.5 | 22 | 75 | 12 |
| R6 | 24 | 75 | 12 |
| R7 | 28 | 100 | 14 |
| R8 | 32 | 100 | 16 |
| R9 | 36 | 100 | 18 |
| R10 | 40 | 100 | 20 |
| Dia (D) | Flute Length (l) | Total Length (L) | Shank Dia (d) |
|---|---|---|---|
| R0.5 | 2 | 75 | 4 |
| R0.75 | 3 | 75 | 4 |
| R1 | 4 | 75 | 4 |
| R1.5 | 6 | 75 | 4 |
| R2 | 8 | 75 | 4 |
| R2.5 | 10 | 75 | 5 |
| R3 | 12 | 75 | 6 |
| R4 | 16 | 75 | 8 |
| R5 | 20 | 100 | 10 |
| R6 | 24 | 100 | 12 |
| R7 | 28 | 150 | 14 |
| R8 | 32 | 150 | 16 |
| R9 | 40 | 150 | 18 |
| R110 | 40 | 150 | 20 |
| Dia (D) | Flute Length (l) | Total Length (L) | Shank Dia (d) |
|---|---|---|---|
| R1.5 | 6 | 100 | 3 |
| R2 | 8 | 100 | 4 |
| R2.5 | 10 | 100 | 5 |
| R3 | 12 | 100 | 6 |
| R3 | 12 | 150 | 6 |
| R4 | 16 | 100 | 8 |
| R4 | 16 | 150 | 8 |
| R5 | 20 | 150 | 10 |
| R6 | 24 | 150 | 12 |
