| Dia (D) | Flute Length (l) | Total Length (L) | Shank Dia (d) |
|---|---|---|---|
| 1 | 3 | 50 | 4 |
| 1.5 | 5 | 50 | 4 |
| 2 | 6 | 50 | 4 |
| 2.5 | 8 | 50 | 4 |
| 3 | 10 | 50 | 3 |
| 3 | 10 | 50 | 4 |
| 3.5 | 12 | 50 | 4 |
| 4 | 12 | 50 | 4 |
| 5 | 15 | 50 | 5 |
| 6 | 18 | 50 | 6 |
| 7 | 21 | 60 | 8 |
| 8 | 24 | 60 | 8 |
| 9 | 27 | 75 | 10 |
| 10 | 30 | 75 | 10 |
| 11 | 33 | 75 | 12 |
| 12 | 36 | 75 | 12 |
| 14 | 45 | 100 | 14 |
| 16 | 45 | 100 | 16 |
| 18 | 45 | 100 | 18 |
| 20 | 45 | 100 | 18 |
| Dia (D) | Flute Length (l) | Total Length (L) | Shank Dia (d) |
|---|---|---|---|
| 1 | 3 | 75 | 4 |
| 1.5 | 5 | 75 | 4 |
| 2 | 6 | 75 | 4 |
| 3 | 15 | 75 | 4 |
| 4 | 15 | 75 | 4 |
| 5 | 20 | 75 | 5 |
| 6 | 25 | 75 | 6 |
| 8 | 30 | 75 | 8 |
| 10 | 45 | 100 | 10 |
| 12 | 60 | 150 | 12 |
| 14 | 60 | 150 | 14 |
| 16 | 60 | 150 | 16 |
| 18 | 60 | 150 | 18 |
| 20 | 60 | 150 | 20 |
| Dia (D) | Flute Length (l) | Total Length (L) | Shank Dia (d) |
|---|---|---|---|
| 3 | 12 | 100 | 3 |
| 4 | 20 | 100 | 4 |
| 5 | 25 | 100 | 5 |
| 6 | 30 | 100 | 6 |
| 6 | 35 | 150 | 6 |
| 8 | 40 | 100 | 8 |
| 8 | 50 | 150 | 8 |
| 10 | 50 | 150 | 10 |
| 12 | 60 | 150 | 12 |
