| Dia (D) | CR (r) | Flute Length (l) | Total Length (L) | Shank Dia (d) |
|---|---|---|---|---|
| 3 | 0.5 | 8 | 50 | 3 |
| 3 | 1 | 8 | 50 | 3 |
| 4 | 0.5 | 10 | 50 | 4 |
| 4 | 1 | 10 | 50 | 4 |
| 5 | 0.5 | 12 | 50 | 5 |
| 5 | 1 | 12 | 50 | 5 |
| 6 | 0.5 | 15 | 50 | 6 |
| 6 | 1 | 15 | 50 | 6 |
| 8 | 0.5 | 20 | 60 | 8 |
| 8 | 1 | 20 | 60 | 8 |
| 10 | 0.5 | 25 | 75 | 10 |
| 10 | 1 | 25 | 75 | 10 |
| 10 | 1.5 | 25 | 75 | 10 |
| 12 | 0.5 | 30 | 75 | 12 |
| 12 | 1 | 30 | 75 | 12 |
| 12 | 1.5 | 30 | 75 | 12 |
| 12 | 2\2.5 | 30 | 75 | 12 |
| 16 | 2\2.5 | 35 | 100 | 16 |
| Dia (D) | CR (r) | Flute Length (l) | Total Length (L) | Shank Dia (d) |
|---|---|---|---|---|
| 3 | 0.5 | 12 | 75 | 3 |
| 3 | 1 | 12 | 75 | 3 |
| 4 | 0.5 | 20 | 75 | 4 |
| 4 | 1 | 20 | 75 | 4 |
| 5 | 0.5 | 20 | 75 | 5 |
| 5 | 1 | 20 | 75 | 5 |
| 6 | 0.5 | 25 | 75 | 6 |
| 6 | 1 | 25 | 75 | 6 |
| 8 | 0.5 | 30 | 75 | 8 |
| 8 | 1 | 30 | 75 | 8 |
| 10 | 0.5 | 40 | 100 | 10 |
| 10 | 1 | 40 | 100 | 10 |
| 12 | 0.5 | 45 | 100 | 12 |
| 12 | 1 | 45 | 100 | 12 |
| Dia (D) | CR (r) | Flute Length (l) | Total Length (L) | Shank Dia (d) |
|---|---|---|---|---|
| 6 | 0.5 | 30 | 100 | 6 |
| 6 | 1 | 12 | 100 | 6 |
| 6 | 1 | 40 | 150 | 6 |
| 8 | 0.5 | 35 | 100 | 8 |
| 8 | 1 | 35 | 100 | 8 |
| 8 | 1 | 50 | 150 | 8 |
| 10 | 1 | 60 | 150 | 10 |
| 12 | 1 | 60 | 150 | 12 |
